1.75 Inch Slip Rope Socket Wireline And Slickline Tools 15/16UN

Name: 175 Inch Slip Rope Socket Wireline And Slickline Tools 1516UN
Brand: Ruixin
Price: 1 USD

Brand Name : Ruixin

Model Number : 1.5inch 1.75inch 1.875inch 2.125inch 2.5inch

Certification : API Q1

Place of Origin : China Baoji

MOQ : 1

Payment Terms : T/T, Western Union

Supply Ability : 1 set 1 week

Delivery Time : 1-2 weeks

Packaging Details : Wooden Box

Name : 2 inch 1.75inch Slip Rope Socket Wireline And Slickline Tools Material aluminum alloy

Material : Material aluminum alloy

Size : 1.5inch 1.75inch 1.875inch 2.125inch 2.5inch

Applicable tubing : 2-3/8inch～2-7/8inch 2-7/8inch～3-1/2inch

Fishing neck : 1.375inch-2.313inch

Connection : 15/16UN 1-1/16UN

Contact Now

2 inch 1.75inch Slip Rope Socket Wireline And Slickline Tools Material aluminum alloy

I. Overview

A slip rope socket is used to attach wireline to the tool string. The upper section is to load and the lower

section is to lead. Fishing neck is available on the top.

II. Common specifications and technical parameters

Size	Applicable tubing	Fishing neck	Connection	PN.
1.5＂	2-3/8＂～2-7/8＂	1.375＂	15/16UN	W01-03.03.00
1.75＂	2-7/8＂～3-1/2＂	1.375＂	15/16UN	W01-03.01.00
1.875＂	2-7/8＂～3-1/2＂	1.75＂	1-1/16UN	W01-03.02.00
2.125＂	3-1/2＂～4-1/2＂	1.75＂	1-1/16UN	W01-03.04.00
2.5＂	Over 4-1/2＂	2.313＂	1-9/16UN	W01-03.05.00

Note: More customized parts are available upon request.

III. Structural features:

The slip rope socket consists of a body, slip, wedge, lower sub, weak point slip, etc., which is mainly

designed for the wireline less than 5/16” (included) .

The body is with various sizes for selection. The weak point slip is slotted. The wireline will be snapped

as soon as the tension of the wireline reaches a definite percentage of the full load. Five kinds of weak

point slip are available for selection, with 50%, 60%, 70%, 80%, 90% of the full load accordingly.

Welcome to contact us at any time.
